Millimar 6105 N
Adjustment ring Millimar 6105 N Cylindricity tolerance: 0,1 x IT4 Ø mm: 3.001 - 4 mm
Millimar 6107 S
Adjustment ring Millimar 6107 S Cylindricity tolerance: 0,1 x IT3 Ø mm: 6.001 - 8 mm
Millimar 6105 N
Adjustment ring Millimar 6105 N Cylindricity tolerance: 0,1 x IT4 Ø mm: 6.001 - 7 mm
Millimar
Adjustment ring Millimar Tolerance class: X Material type: hardened steel Ø mm: 9.3 - 13 mm
Millimar 6105 N
Adjustment ring Millimar 6105 N Cylindricity tolerance: 0,1 x IT4 Ø mm: 4.001 - 6 mm
Millimar 6107 S
Adjustment ring Millimar 6107 S Cylindricity tolerance: 0,1 x IT3 Ø mm: 4.001 - 6 mm
