Mahr Metrology Compact
User seminar for newcomers to production metrology
User seminar for newcomers to production metrology
This seminar is ideally suited for newcomers to metrology. During these two days, topics on surface, form and position, length and gear metrology will be taught in a compact and understandable way in order to gain important basic knowledge. All topics are supplemented with small exercises and applications. This seminar forms the optimum basis for all subsequent topics in the field of metrology.
Course contents
1. Surface roughness: ISO 1302, 4287, 4288, 3274
2. Form and location measurement: ISO 1101 (central points)
3. Gear measurement: basics of gearing and measurement methods
4. Length measurement: ISO 14405
Book nowSuitable for
Beginners
Completion
Mahr Academy certificate
