Mahr Basics of Surface Metrology
Basic training for users of roughness measuring instruments
Basic training for users of roughness measuring instruments
This seminar is aimed at those who would like to receive initial training in the use of roughness measuring technology. Participants will learn handling and care, as well as the basic operating elements of successful roughness measuring machine use.
Course contents
1. Selection of cut-off wavelengths and filters
2. Recognition and evaluation of standard parameters
3. Drawing entries ISO / VDA
4. Introduction to surface scanners and calibration
5. Practical hints for measurement
Book nowSuitable for
beginners
Completion
Mahr Academy certificate
Course number
9967149
