Focus Week Surface Metrology
Intensive focus training for users of surface metrology in quality assurance, measuring room and many more
Intensive focus training for users of surface metrology in quality assurance, measuring room, construction, laboratory, production and work preparation
Intensive focus training for users of surface measurement technology in quality assurance, measuring room, construction, laboratory, production and work preparation
This detailed intensive training course with a focus on surface measurement consists of all important information on surface measurement as well as practical, hands-on user training. This allows participants to directly combine theory with practice and thus learn even more efficiently.
Course contents
1. Selection of cut-off wavelengths and filters
2. Recognition and evaluation of standard parameters
3. Drawing entries ISO / VDA
4. Introduction to waviness, twist and surface characteristics according to ISO 25178
5. Introduction to surface gauges and calibration
6. Practical hints for measurement
Suitable for
Technical staff with relations to surface measurement
Completion
Mahr Academy Certificate
