AUKOM Measurement Technician
This certificate course entitles you to participate in the expert training AUKOM 3
This certificate course entitles you to participate in the expert training AUKOM 3
You will receive the AUKOM Measurement Technician certificate if you have successfully completed both the AUKOM Level 1 & 2 examination and the AUKOM Geometric Dimensioning & Tolerancing seminar. These seminars can each be completed individually, or you can attend the combined intensive training Focus Week AUKOM Geometric Dimensioning & Tolerancing. With the officially recognized title of AUKOM Measurement Technician, you can participate in the AUKOM 3 expert training.
You will receive the AUKOM Measurement Technician certificate following completion of the last course passed (AUKOM 1, AUKOM 2, AUKOM Geometric Dimensioning & Tolerancing).
Go to AUKOM Geometric Dimensioning & TolerancingSuitable for
Advanced students with AUKOM Certificate Level 1 & 2, as well as graduates of the AUKOM Geometric Dimensioning & Tolerancing seminar or graduates of the combined intensive training Focus Week AUKOM Geometric Dimensioning & Tolerancing. Participants from previous seminars (completed before 2020) additionally require completion of the AUKOM Update Seminar.
Completion
AUKOM Measurement Technician Certificate with a validity period of 5 years
Follow-up seminar
AUKOM Update, if applicable
AUKOM Level 3
