MarStand 815 XN
Art. no. 4424000
Post and support assemblies 815 XN
- Sturdy design for mounting in a T-slot
- Two joints
- Knurled nut for clamping
- Post and support arm are made of stainless steel
- With fine adjustment
Total height 245 mm
with slot nut
- Two joints
- Knurled lock nut to attach column
- Stainless steel column and cantilever arms
- Fine adjuster
| Total height | 245 mm |
| Dimensions | |
|
|
|
