MarConnect 2000 USB
Art. no. 4346023
2000 USB
Data connection cable USB (2 m)
- For connecting the measuring instrument to a PC
- Data transfer to MarCom or to other applications via virtual COM interface
| Product type |
2000 USB |
| For measuring instrument |
Digimar 816 CL MarCator 1088, 1088 W Millimess 2000, 2001, 2100, µMaxum II |
| Data interface | USB |
| Hardware interfaces | Extramess-Interface , Duplex , USB |
| Cable length | 2 m |
| Label | Art. no. | Product type | Inputs | Data interface | Hardware interfaces | |
|---|---|---|---|---|---|---|
|
Remote control for MarCom MC-R |
4102221 | MC-R | |||
|
USB-Hub 7-fold industrial model USB hub |
4102553 | USB hub |
|
USB | USB |
MarConnect DK-U1
MarConnect 16 EXu
16 EXu Data connection cable USB (2 m)
MarConnect MC-I
MC-I Adaption cable (for foot swich via MarCom): jack plug Ø 3.5 mm/USB (0.1 m)
MarConnect 800 EWu
800 EWu Data connection cable USB (2 m)
MarConnect Millimar - USB
Millimar - USB Adapter cable RS-232-USB (0.2 m)
MarConnect Opto USB
Opto USB Opto USB Adapter cable RS232-USB (0.2 m) incl. Software MarCom Std.
MarConnect 817 USB
817 USB Adapter cable RS232-USB (0.2 m)
