MarCator O3I
Art. no. 2011770
Dial indicator MarCator O3I
ANSI
Measuring span in mm: 1.25mm
Graduation value mm: 0.005
Figur on dial face: 0-25-0
| MarCator O3I | Art. no. 2011770 | |
|---|---|
| Product type | O3I |
| Measuring span in mm | 1.25 mm |
| Graduation value mm | 0.005 |
| Range per rev. in mm | 0.5 mm |
| Error limit measuring range µm | 10 µm |
| Figur on dial face | 0-25-0 |
| Dial color | Yellow |
| Scale diameter | 45 mm |
|
|
MarCator O6I
Dial indicator MarCator O6I ANSI Measuring span in mm: 2.5mm Readings_mm: 0.01 Figur on dial fa...
MarCator O8I-RC
Dial indicator MarCator O8I-RC ANSI Measuring span in mm: 6.25mm Readings_mm: 0.025 Figur on di...
MarCator O3I-RC
Dial indicator MarCator O3I-RC ANSI Measuring span in mm: 1.25mm Readings_mm: 0.005 Figur on di...
MarCator O1I
Dial indicator MarCator O1I ANSI Measuring span in mm: 0.5mm Readings_mm: 0.002 Figur on dial f...
MarCator O8I
Dial indicator MarCator O8I ANSI Measuring span in mm: 6.25mm Readings_mm: 0.025 Figur on dial ...
MarCator O6I-RC
Dial indicator MarCator O6I-RC ANSI Measuring span in mm: 2.5mm Readings_mm: 0.01 Figur on dial...
