MarCator 810 S
Art. no. 4311000
Mechancial dial indicator MarCator 810 S
DIN 878
Measuring span in mm: 10mm
Graduation value mm: 0.01
Package contains: case
- High contrast dial face
- Adjustable tolerance markers
- Chrome plated housing
- Lifter protection cap on the measuring spindle
- Precision gears and pinions
| Product type | 810 S |
| Measuring span in mm | 10 mm |
| Range per rev. in mm | 1 mm |
| Graduation value mm | 0.01 |
| Error limit measuring range µm | 15 µm |
| Error limit 1 revolution µm | 10 µm |
| Error limit 1/2 revolution µm | 9 µm |
| Error limit 1/10 revolution µm | 5 µm |
| Measuring value hysteresis fu (µm) | 3 µm |
| Repeatability fw (µm) | 3 µm |
| Figur on dial face | 0 - 100 |
| Dial color | White |
| Scale diameter | 50 mm |
| Dimensions | a 58 mm | b 23 mm | c 7.5 mm | d 52 mm | e 112 mm | f 21 mm | g 16 mm |
|
|
MarCator 810 A
Mechancial dial indicator MarCator 810 A DIN 878 Measuring span in mm: 10mm Readings_mm: 0.01 P...
MarCator 810 AU
Mechancial dial indicator MarCator 810 AU Factory standard Measuring span in mm: 10mm Readings_mm...
MarCator 810 AT
Mechancial dial indicator MarCator 810 AT DIN 878 Measuring span in mm: 10mm Readings_mm: 0.01 ...
MarCator 810 SV
Mechancial dial indicator MarCator 810 SV Factory standard Measuring span in mm: 40mm Readings_mm...
