Millimar A 1701 M: Signal converter for automation
Users can combine the module with all inductive probes from Mahr or compatible products from other manufacturers. The resulting measuring system is suitable for testing tasks in automated processes and can be easily integrated into an existing production infrastructure, for example in plant engineering.
Equipped with an input for inductive probes, the Millimar A 1701 M picks up the incoming carrier frequency signal and converts it into a standardized analog signal, for example ±10 volts or 0 to 10 volts. It offers various standards as signal outputs. Overall operation is uncomplicated, for example measuring ranges and filters are easy to set. An LED display provides information on the operating status at all times. The compact and robust housing facilitates use in the production environment and can be mounted on a top-hat rail if required.
(1,130 characters incl. spaces)
Source reference:
Image: Mahr GmbH
Download:
↓ 300dpi (2000 × 1500 px)
About the Carl Mahr Group
Highest precision, modern technology and international presence – that is what the name Mahr has stood for, for more than 160 years. Today, the Mahr Group, with its three business units Metrology, Mixing & Metering, and Rotary Stroke Bearings, is active worldwide in a wide range of demanding industries, such as automotive, mechanical engineering, medical technology, aerospace, optics, electronics. All products incorporate the passion and know-how of more than 1,800 employees worldwide.
